Uni-T UT61D+ True RMS Digital Multimeter, CAT IV 600V, 20A
Model # UT61D+Key Features
?
Question about this product?
Features
- Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature
- A reliable true RMS digital multimetes with 6000 display counts
- It can measure up to 1000V AC/DC
Technical Information
- DC Voltage1000V
- AC Voltage1000V
- AC Current20A
- DC Current20A
- Resistance60MΩ
- Capacitance60mF
- Frequency10MHz
- Display Count6000
- Safety RatingsCAT III 1000V / CAT IV 600V
- Duty Cycle(%) range0.1% - 99.9%
- Bandwidth Range40Hz - 1kHz
- LoZ ACVYes
- Peak HoldYes
- Analog Bar Range31
- Dimensions190 x 90 x 50mm
Items Included
- Battery
- gold plated test leads
- USB cable
- temperature probe
- English manual
