Metabo 601714800 KH 18 LTX BL 24 Q SDS-Plus Cordless 18V Combination Hammer, 2.2 J, Drill-Ø 24 mm

Model #   601714800

?

Question about this product?

Speak to an expert

Learn how to use

Features

  • Extremely light and compact cordless hammer with integrated extraction interface
  • Maximum drill performance, efficiency and service life thanks to brushless technology and high-performance hammer action
  • Dust-free drilling with compact dust extraction ISA 24 (accessory)
  • Combination hammer with 3 functions: hammer drilling, drilling and chiselling
  • Metabo VibraTech (MVT): integrated damping system to reduce vibrations in order to protect the user's health
  • Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for many different applications
  • Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
  • Electronic soft start for precise spot-drilling
  • Double safety when the drill bit jams: No kick-back thanks to the mechanic decoupling plus ultra-fast sensor-controlled shutdown
  • LED work light for optimum view of the drilling site
  • Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com

Technical Information

  • Type of battery pack LiHD
  • Battery voltage 18 V
  • Battery pack capacity 2 x 4 Ah
  • Max. single blow energy (EPTA) 2.2 J
  • Maximum impact rate 4750 bpm
  • Drill-Ø concrete with hammer drills 24 mm / 1 "
  • Drill-Ø masonry with core bits 82 mm / 3 7/32 "
  • Drill Ø steel 13 mm / 1/2 "
  • Drill-Ø soft wood 30 mm / 1 3/16 "
  • No-load speed 0 - 1280 rpm
  • Bit retainer SDS-plus
  • Weight without battery pack 3 kg / 6.61 lbs

Items Included

  • Hammer chuck for tools with SDS-plus shank end
  • Drilling depth guide
  • 2 LiHD Battery packs (18 V/4.0 Ah)
  • Charger ASC 55 "AIR COOLED"
  • MetaBOX 165 L
  • Keyless chuck for tools with cylindrical shank
  • Rubber-coated side handle
