Thumbnail 0

Megger LRCD210-EN-BS Advanced Loop and RCD Tester with 1/2xI, 1xI, and 5xI RCD Testing

Model # LRCD210-EN-BS

Key Features

Brand: Megger
Model: LRCD210-EN-BS
Warranty: 3 years

Qty:

Qty:

?

Question about this product?

Speak to an expert

Features

Non-trip loop tester for 3-phase safe non-trip loop testing
RCD testing for 1/2xI, 1xI, and 5xI for standard, selective, and pulsed DC RCDs
IP54 weatherproof with tough rubber-armored case
Non-tripping loop testing for RCDs rated 30 mA or higher
Supply voltage and frequency display
PFC (Prospective Fault Current) calculation
Touch voltage display with selectable 25 V or 50 V
Type AC, A, and S RCD testing with 0/180-degree selection
Ramp testing (20% to 110% of rated current)

Technical Information

Voltage Measurement0V to 500V
Frequency Measurement25 Hz to 450 Hz
Phase Rotation IndicatorNo
Loop TestingNon-trip Loop Test (3-wire)
Supply Voltage200V to 280V
Nominal Test Current15 mA
Loop Accuracy0.01 Ω – 2.00 kΩ
RCD Testing Ranges10 mA, 30 mA, 100 mA, 300 mA, 500 mA
RCD Testing Features1/2xI, 1xI, and 5xI testing, Type AC, A, and S RCD testing, 0/180-degree selection
Test Current AccuracyNo Trip Test
Touch Voltage DisplayYes
Environmental ProtectionIP54
Battery Type8 x 1.5 V cells IEC LR6 type (AA alkaline)
Weight980 g
Dimensions203 mm x 148 mm x 78 mm

Items Included

Red/Black/Green 3 wire lead set
BS1363 Mains plug test lead
