Thumbnail 0

Megger LRCD200-EN-BS Basic Non-Trip Loop and RCD Tester with 3-Phase Safe Testing and 500 mA RCD Range

Model # LRCD200-EN-BS

Key Features

Brand: Megger
Model: LRCD200-EN-BS
Warranty: 3 Years

Qty:

Qty:

?

Question about this product?

Speak to an expert

Features

Non-trip loop tester for 3-phase safe non-trip loop testing
RCD testing for 10 mA to 500 mA RCDs, with 1xI test
Not suitable for UK applications
IP54 weatherproof with a tough rubber-armored case
Non-tripping loop testing on RCDs rated 30 mA or higher, even for electronic RCDs
Supply voltage and frequency display
PFC (Prospective Fault Current) calculation and display
Loop resistance measurements from 0.01 ohms to 2 kohms

Technical Information

Voltage Measurement0V to 500V
Frequency Measurement25 Hz to 450 Hz
Phase Rotation IndicatorNo
Loop TestingNon-trip Loop Test (3-wire)
Supply Voltage200V to 280V
Nominal Test Current15 mA
Loop Accuracy0.01 Ω – 2.00 kΩ
RCD Testing Ranges10 mA, 30 mA, 100 mA, 300 mA, 500 mA
Touch Voltage DisplayYes (Optional)
Environmental ProtectionIP54
Battery Type8 x 1.5 V cells IEC LR6 type (AA alkaline)
Weight980 g

Items Included

Red/Black/Green 3 wire lead set
BS1363 Mains plug test lead
