Klauke EK354MLSETHL 10.8V Cordless Hydraulic Crimping Tool, 150mm² with Copper Dies (6-150mm²)
Model # EK354MLSETHLKey Features
?
Question about this product?
Features
- Large cross section range up to 150mm²
- Slim crimping head - ideal when space is critical
- Powerful 10.8V Li-Ion battery technology with battery charge indicator
- Closed head, flip top style, rotatable
- Simple and safe: one-button operating concept for controlling all tool functions
- Comfortable and secure one-hand operation thanks to 2-component plastic housing with soft lining
- Effortless operations thanks to low weight
- Automatic retraction when operation is complete
- Maintenance display via LED
- Suitable For: 4-series interchangeable crimping dies, narrow crimping
Technical Information
- Crimping Force35kN
- Stroke9mm
- Crimping Capacity6-150mm²
- Crimping Cycle3-4s (depending on cross section)
- Number of crimps140 (for 120mm² Cu, approx)
- Voltage10.8V
- Battery Capacity1.5Ah
- Battery Charging Time40min.
- Weight Including Battery1.6kg
- Ambient Temperature-10 to 40°C
Items Included
- RAML1 - 10.8V / 1.5 Ah, Li-Ion (16.2 Wh) battery
- LGML1 - Charger for 10.8V Li-Ion batteries, 230V
- KKML - Hard plastic carrying case
- HL4/6mm² Crimping Die
- HL4/10mm² Crimping Die
- HL4/16mm² Crimping Die
- HL4/25mm² Crimping Die
- HL4/35mm² Crimping Die
- HL4/50mm² Crimping Die
- HL4/70mm² Crimping Die
- HL4/95mm² Crimping Die
- HL4/120mm² Crimping Die
- HL4/150mm² Crimping Die
