Fluke 750PA4Ex Intrinsically Safe Pressure Module, 0 to 15 PSIA, 0 to 1 Bar

Features

• Digital communication eliminates errors due to poor connections and electrical interference
• The modules are inherently temperature compensated from 0 to 50¡C (32 to 122¡F)
• The modules are fully interchangeable because all measurements are completed in the pressure module itself and then communicated to the calibrator in digitized form
• Modules are calibrated independently of the calibrator, and can be used with any 718Ex or 725Ex calibrator
• Quick and easy measurements
• Rugged construction
• Convenient setup
• Sensor protection in isolated modules

Technical Information

• Range0 to 15 PSIA
• Accuracy±0.07%
• Product Dimensions (WxHxD)4 x 4.5 x 2" (101 x 114 x 50mm)
• Weight2 lbs

Items Included

• Pressure Module Traceable Calibration Certificate Adapters Manual

Downloads

Datasheet
