Fluke 717 30G Pressure Calibrator, -12 To 30 PSI, -850 mBar to 2 Bar

Features

• Measure pressure and vacuum to 0.05% of full scale with the internal 30 psig sensor (30G Model)
• 1/8 NPT pressure fitting
• Compatible with non-corrosive gasses and liquids
• Measure pressure -85 to 207 kPa using one of the Fluke 750 Series Pressure Modules
• Calibrate P/I instruments with simultaneous pressure and current measurement
• Error% calculation of mA measurements for quick pass-fail decisions
• Long lasting battery life
• Holster features test lead storage
• Compatible with Toolpack magnetic hanging system

Technical Information

• Range-12 to 30 psi, (-850 mbar to 2 bar, -83 to 206.84 kPa)
• Resolution0.001 psi, 0.1 mbar, 0.01 kPa
• Over Pressure2 x full scale
• Current0 to 24 mA (-25% to 125%)
• Accuracy0.015% + 2 counts
• Loop Power24V DC
• Accuracy±10%
• DisplayClear 5 digit LCD
• Operating temperature-10°C to 55°C
• Storage temperature-40°C to 60°C
• Humidity (without condensation)95% (10°C to 30°C)
• Operating altitude3,000 M max

Items Included

• 1 – Test Lead Set
• 1 – Alligator Test Clip Set
• 1 – Protective Yellow Holster with Test Lead Storage 1 – 9V Battery
• 1 – NIST Calibration Report and Data
• 1 – User Manual

Downloads

Datasheet
