Fluke 717 1G Pressure Calibrator, -1 to 1 PSI, -68.9 to 68.9 mBar

Features

• -1-1 psi delivers outstanding performance, durability and reliability.
• The calibrator is compact, lightweight, and easy to carry.
• With a push button interface, the 717 1G is easy to use. It is EMI tolerant, dust and splash resistant, and features a removable battery door for quick battery changes.
• Range: -1 to 1 psi (-68.9 mbar to 68.9 mbar, -83 to 6.89 kPa)
• 1/8 NPT female pressure fitting
• Compatible with non-corrosive Gases and liquids
• Zero, min, max, and hold functions
• Calibrate P/I instruments with simultaneous pressure and current measurement
• Error% calculation of mA measurements for quick pass-fail decisions

Technical Information

• Range-1 to 1 psi, (-68.9 mbar to 68.9 mbar, -83 to 6.89 kPa)
• Resolution0.0001 psi, 0.001 mbar, 0.0001 kPa
• Over pressure5 x full scale
• Current0 to 24 mA (-25% to 125%)
• Resolution0.001 mA
• Accuracy0.015% + 2 counts
• DisplayClear 5 digit LCD
• Operating temperature-10°C to 55°C
• Storage temperature-40°C to 60°C
• Humidity (without condensation)95% (10°C to 30°C)
• Operating altitude3,000 M max
• Size (L x W x H)201 x 98 x 52 mm (7.93 x 3.86 x 2.06 in)

Items Included

• 1 – Test Lead Set
• 1 – Alligator Test Clip Set
• 1 – Protective Yellow Holster with Test Lead Storage
• 1 – 9V Battery
• 1 – NIST Calibration Report and Data
• 1 – User Manual

Downloads

Datasheet
