Fluke 717-15G Pressure Calibrator 15 PSIG, 1 Bar

Features

• Measure pressure and vacuum to 0.05% of full scale with the internal 15 psig sensor (15G Model)
• 1/8 NPT pressure fitting
• Compatible with non-corrosive gasses and liquids
• Measure pressure -85 to 103 kPa using one of the Fluke 750 Series Pressure Modules
• Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
• Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)
• Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
• Select eleven different engineering units
• Zero, min, max, and hold functions

Technical Information

• Range29 pressure modules, 0 – 1 in H20 to 10,000 PSI, 2.5 mbar to 700 bar ranges over pressure per pressure module specs
• ResolutionPer pressure module specs
• Accuracy0.025 % of full span, per pressure module specs
• FunctionsZero, Min, Max, Hold, Damp, error calculation
• NoteMedia compatibility per pressure module specs

Items Included

• Protective Yellow Holster with test lead storage
• Instructions Sheet (14 languages)
• Single 9V alkaline battery
• Test Leads and Alligator Clips
• NIST- traceable calibration report and data

Downloads

Datasheet
