Fluke 717-10000G Pressure Calibrator, 10000 PSIG

Features

• The Fluke 717 Pressure Calibrators delivers outstanding performance, durability and reliability. These calibrators are compact, lightweight, and easy to carry. With a push button interface similar to the multifunction Fluke 740 Series Documenting Process Calibrators, the 717s are easy to use. They are EMI tolerant, dust and splash resistant, and feature a removable battery door for quick battery changes.
• These calibrators come in 9 models measuring pressure up to 5000 psi/345 bar and are compatible with Fluke 700Pxx differential, gauge and absolute pressure modules to increase functionality.
• Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)
• Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
• Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
• 1/8 NPT female pressure fitting
• Compatible with non-corrosive Gases and liquids
• Select eleven different engineering units
• Zero, min, max, and hold functions

Technical Information

• Range29 pressure modules, 0 – 1 in H20 to 10,000 PSI, 2.5 mbar to 700 bar ranges over pressure per pressure module specs
• ResolutionPer pressure module specs
• Accuracy0.025 % of full span, per pressure module specs
• FunctionsZero, Min, Max, Hold, Damp, error calculation
• NoteMedia compatibility per pressure module specs

Items Included

• Protective Yellow Holster with Test Lead Storage
• Instructions Sheet (14 languages)
• Single 9V Alkaline Battery
• Test Leads and Alligator Clips
• NIST- Traceable Calibration Report and Data

Downloads

Datasheet
