Fluke 700RG31 Pressure Test Gauge, -14 To 10,000 PSI

Features

• Rugged high-quality pressure gauge calibrator for fast accurate test results. 10000 PSIG.
• ATEX: rating II 3 G Ex nA IIB T6
• Precision pressure measurement from ±10 inH2O/20 mbar to 10;000 psi/690 bar
• Absolute pressure measurement ranges 15; 30; 100; 300 psia
• Reference class gauge accuracies to 0.04% of reading
• Easy to use, rugged construction for reliable performance
• CSA; Class 1, Div 2, Groups A-D rating
• ATEX rating: II 3 G Ex nA IIB T6

Technical Information

• Range-14 psi to 10000 psi/-.97 bar to 690 bar
• Resolution1 psi/0.01 bar
• AccuracyPositive pressure ± 0.05 % FS Vacuum ± 0.1 % FS
• Burst Pressure20000 psi/1035 bar
• Pressure Connection¼" NPT male
• Display5½ digits, 16.53 mm (0.65 in) high 20-segment bar graph, 0 to 100 %
• Power3 x AA alkaline batteries
• Battery Life1500 hours without backlight (continuous on), 2000 hours at slow sample rate
• Dimensions5 x 4.5 x 1.5" (12.7 x 11.4 x 3.7 cm)

Items Included

• Fluke 700RG31 Pressure Test Gauge
• -14 to 10
• 000 psi reference

Downloads

Datasheet
