Fluke 700RG06 Pressure Test Gauge, -12 To 100 PSI

Features

• Portable; high-quality round pressure gauge calibrator for fast and accurate calibration test results
• Combined with either the 700PTPK pneumatic pump kit or the 700HTPK hydraulic pump kit for a complete measurement and testing solution
• Precision pressure measurement from ±10 inH2O/20 mbar to 10;000 psi/690 bar
• Absolute pressure measurement ranges 15; 30; 100; 300 psia
• Reference class gauge accuracies to 0.04% of reading
• Easy to use, rugged construction for reliable performance
• CSA; Class 1, Div 2, Groups A-D rating
• ATEX rating: II 3 G Ex nA IIB T6

Technical Information

• Range-12 psi to 100 psi/-.83 bar to 6.9 bar
• Resolution0.001 psi/0.0001 bar
• AccuracyPositive pressure ± 0.05 % FS Vacuum ± 0.1 % FS
• Burst Pressure400 psi/26 bar
• Pressure Connection¼" NPT male
• Display5½ digits, 16.53 mm (0.65 in) high 20-segment bar graph, 0 to 100 %
• Power3 x AA alkaline batteries
• Battery Life1500 hours without backlight (continuous on), 2000 hours at slow sample rate
• Dimensions5 x 4.5 x 1.5" (12.7 x 11.4 x 3.7 cm)

Items Included

• Fluke 700RG06 Pressure Test Gauge
• -12 to 100 psi reference

Downloads

Datasheet
