Fluke 700G27 Pressure Test Gauge, -12 to 300 PSI, 20 Bar

Features

• Bright backlit display for easy viewing of pressure measurements
• Rugged; durable design with protective holster
• High accuracy; 0.05% total measurement uncertainty for one year
• Combined with either the 700PTPK pneumatic pump kit or the 700HTPK hydraulic pump kit for a complete measurement and testing solution
• Rugged design with intrinsically safe certification
• Standard accuracy to 0.05% of full scale
• Allows you to work safely in classified areas known to include explosive gasses
• Easily view in most environments with bright backlit display
• Make precise pressure measurements from ±10 inH2O/20 mbar to 10,000 psi/690 bar

Technical Information

• Range-12 to 300 psi, -0.83 to 20 bar
• Resolution0.01 psi, 0.001 bar
• AccuracyPositive pressure ± 0.05 % FS Vacuum ± 0.1 % FS
• Burst Pressure1200 psi, 80 bar
• Dimensions (HxWxD)12.7 cm x 11.4 cm x 3.7 cm (5 in x 4.5 in x 1.5 in)
• Pressure connection1/4 in NPT Male, ( 1/4 in NPT to 1/4 ISO adapter provided)
• Weight0.56 kg, 1.22 lbs with holster
• Display5-1/2 digits, 16.53 mm (0.65 in) high 20 –segment ar graph, 0 to 100 %
• Battery life1,500 hours without backlight (continuous on), 2,000 hours at slow sample rate

Items Included

• Manual on CD-ROM in 14 languages
• Traceable certificate of calibration
• 1/4" NPT to 1/4" ISO adapter

Downloads

Datasheet
