Fluke 700G02 Pressure Test Gauge, -1 to 1 PSI, -70 to 70 mBar

Features

• Bright backlit display for easy viewing of pressure measurements
• Rugged; durable design with protective holster
• High accuracy; 0.05% total measurement uncertainty for one year
• Combined with either the 700PTPK pneumatic pump kit or the 700HTPK hydraulic pump kit for a complete measurement and testing solution
• Rugged design with intrinsically safe certification
• Standard accuracy to 0.05% of full scale
• Allows you to work safely in classified areas known to include explosive gasses
• Easily view in most environments with bright backlit display
• Make precise pressure measurements from ±10 inH2O/20 mbar to 10,000 psi/690 bar

Technical Information

• Range-1 to +1 psi, -70 mbar to 70 mbar
• Resolution0.0001 psi, 0.001 mbar
• AccuracyPositive pressure ±0.1% of range, Vacuum ±0.1% of range
• Burst Pressure5 psi, 350 mbar
• Dimensions (H x W x D)12.7 x 11.4 x 3.7 cm (5 x 4.5 x 1.5 in)
• Pressure connection¼ in NPT Male
• Weight0.56 kg (1.22 lb) with holster
• Display5-1/2 digits, 16.53 mm (0.65 in) high 20-segment bar graph, 0 to 100%
• PowerThree (3) AA alkaline batteries
• Battery life1,500 hours without backlight (continuous on), 2,000 hours at slow sample rate

Items Included

• Fluke 700G Pressure Gauge Calibrator
• Manual on CD-ROM in 14 languages
• Traceable certificate of calibration
• 1/4˝ NPT to 1/4˝ ISO adapter

Downloads

Datasheet
