Fluke 289/EUR True RMS Electronics Logging Multimeter, CAT IV 600V, 10A

Features

• Large 50;000 count; ¼ VGA display with white backlight.
• Multiple sets of measurement information can simultaneously displayed at the same time
• 50 ohm range – useful for measuring and comparing differences in motor winding resistance; low ohm measurements; or other contact resistance.
• Two terminal 50 ohm range with 1 milliohm resolution; 10 mA source current.
• Provides up to a 14x zoom to view and analyze TrendCapture data in depth
• Includes a selectable AC filter (smoothing mode) to help display a steadier reading when the input signal is changing rapidly or noisy.
• Multiple logging sessions possible without download.
• Multi-lingual interface.

Technical Information

• DC voltage1000V
• AC voltage1000V
• DC current10A
• AC current10A
• Resistance50Ω to 500MΩ
• Capacitance1nF to 100mF
• Frequency99.999Hz to 999.99kHz
• Temperature-200.0°C to 1350.0°C
• Safety RatingCAT IV 600V, CAT III 1000V
• Battery type6 AA alkaline batteries, NEDA 15A IECLR6
• TemperatureOperating: -20°C to 55°C
• Weight870.9 g (28 oz)

Items Included

• 289 True-RMS Industrial Logging
• Multimeter
• TL71 Test Leads
• AC175 Alligator Clips
• Batteries – 6 AA Installed

Downloads

Datasheet
