Fluke 190-202/S Scopemeter® Oscilloscope with FlukeView Software, 2 Channel, 200 MHz
Model # 190-202/SDiscontinued
Key Features
?
Question about this product?
Features
- Combines an unprecedented level of performance; ruggedness; and portability with 200 MHz bandwidth and real-time sampling rates up to 2.5 GS/s and 200 ps resolution to capture noise and other disturbances.
- With FlukeView ScopeMeter software
- Two electrically isolated inputs with SCC-290 Kit
- CAT III 1000 V / CAT IV 600 V safety rated
- Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details
- Dedicated 5000 Count digital multimeter
- Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering
- ScopeRecord roll mode, capture waveform sample data for up to 48 hours
- TrendPlot, trend measurement readings for up to 22 days
Technical Information
- Real-time sample rate2.5 GS/s
- Number of channels2 channels
- Timebase range2 ns - 2 min/div
- Input sensitivity2 mV-100 V/div
- Operating temperature0 °C to 40 °C Including Batteries
- Storageemperature-20 °C to +60 °C
Items Included
- Color ScopeMeter
- 200 MHz
- 2 channels plus DMM/Ext.input with SCC-290 Kit
