Fluke 190-062 Scopemeter, 2 Channel, 60 MHz
Model # 190-062Discontinued
Key Features
?
Question about this product?
Features
- Features 60MHz bandwidth; 625MS/s compatible with CAT IV applications; 2 inputs.
- 2 Isolated Floating Channels
- 100V CAT III / 600V CAT IV
- Two electrically isolated inputs
- Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details
- Dedicated 5000 Count digital multimeter in 2 Channel models
- Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering
- ScopeRecord roll mode, capture waveform sample data for up to 48 hours
- TrendPlot, trend measurement readings for up to 22 days
Technical Information
- Real-time sample rate625 MS/s
- Number of channels2 channels
- Inputs2 scope plus DMM input
- Timebase range10 ns - 2 min/div
- Input sensitivity2 mV-100 V/div
- Display153 mm full color LCD with fast update rate
- Operating temperature0°C to 40°C Including Batteries
- Storage temperature-20°C to +60°C
- Size270 x 190 x 70 mm
Items Included
- Color ScopeMeter
- 60 MHz
- 2 channels plus DMM/Ext.input
