Extech 380396 Digital Insulation Tester, CAT IV 600V, 500V - 5000V
Model # 380396Key Features
?
Question about this product?
Features
- Test Voltages of 500V, 1000V, 2500V, and 5000V
- Measure Insulation Resistance to 60GOhm
- Large 6000 count display with bargraph and backlight
- Polarization Index measurement (PI)
- Dielectric Absorption Ratio measurement (DAR)
- AC/DC Voltage measurement from 0 to 600V with Max/Min, Peak and Relative functions
- 1 to 15 minute timer function for IR measurements
- Resistance measurement
- Indication of output voltage and discharge voltage
Technical Information
- Test Voltage500V/1000V/2500V/5000V
- Insulation Resistance0 to 6MΩ , 0 to 60MΩ , 0 to 600MΩ , 0 to 6GΩ , 0 to 60GΩ
- Accuracy±2.5% of reading
- AC/DC Voltage0 to 600V
- Resistance0 to 600Ω
- Accuracy±1.5% of reading
- Continuity50Ω
- PowerEight type C batteries
- Dimensions7.8 x 5.8 x 3.4in (198 x 148 x 86mm)
- Weight3.2lb (1438g)
Items Included
- Test leads
- 8 x C batteries
- 220V AC adaptor
- Heavy duty
- Carrying case
